整机性能特点:Functions and features:
| 整机电器及电脑软件均采用，质量稳定；采用人机界面，电脑订单管理，操作方簌,换单。(可预存999个订单) | The whole machine is adopted international famous brand appliances and computer software,the quality is stable and reliable Man-machine interface, computer order management easy to operate.Replace the order faster ( can be stored 999 orders in advance) |
| 整机墙板及重要部件, 均采用时效处理，回火金属内应力；均采用加工中心制作，数控磨床研磨加工。 | Whole wallboard and important components are adopted aging treatment, eliminate the metal internal stress;Adopt high precision machining centers, CNC grinding machine for grinding processing. |
| 整机轴、辊均采用钢材，研磨加工，电脑动平衡校正，表面镀硬铬。 | The machine shaft, roller are adopted high quality steel, grinding processing, high precision computer dynamic balancing correction and surface hard chromium plating. |
整机传动齿轮全部采用20CrMnTi合金钢，渗碳淬火处理，硬度HRC58–62;经磨齿加工，6级精度，长期使用套色。 | The engine drive gear is adopted 20CrMnTi alloy steel carburizing,quenching treatment, hardness HRC58-62 and gear grinding processing precision level 6, and ensured the long-term use of tinted with high precision |
| 整机传动部位( 轴、齿连接处) , 均采用免键连接(胀紧套) ，连接间隙，适合大扭矩长期高速运转。 | Machine transmission parts (shaft, gear joint) are adopted free key connection (LOCK-ALX), the connection eliminate clearance. It is suitable for long-term high speed with high torque. |
整机传动轴承，重要传动部件均采用加强型调心轴承，维护简便，使用。( 采用三大:“哈瓦洛”) | The machine drive bearing ,important driving parts adopt Heavyduty self-aligning bearing ,simple maintenance,long service life. (three big domestic famous brand:Hava los) |
| 整机润滑系统采用喷淋式自动润滑，配备双油路油位平衡系统。 | The engine lubrication system is adopted automatic spray type lubrication, equipped with double oil level balance system. |
| 整机调整预置位功能，送纸、印刷、开槽、 模切,自动归零，记忆自动复位。 | The machine is adopted adjustment preset functions, feeding printing, slotting, die-cutting, automatic zero resetting memory automatic reset. |
| 整机工作间隙调整，采用免扳手调整，执行调整、方便。 | It adopts Working gap adjustment, rapid adjustment without wrench, quick performance and convenient adjustment. |
| 主机采用交频控制，启动、运转更平稳，。 | The main motor is adopted frequency conversion control. It makes start, running more steadily and saves more energy. |
| 选装：陶瓷网纹辊；刮刀定墨系统；堆码机。 | Optional: ceramic anilox roller, scraper and set ink system, stacking machine. |
| 设有缺墨报警装置，实时监测供墨系统工作状态。 | There is lack of ink alarm device and the real-time monitoring for the ink working condition system. |
主要技术参数：Main technical parameter:
机型 Modle | 0918 | 0920 | 1223 | 1226 | 1423 | 1426 | 1626 | 1629 | |
机械高速度 Max.machine speed P/min | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 180 | |
大过纸 Max.feeding size mm | 900*2000 | 900*2200 | 1200*2500 | 1200*2800 | 1400*2500 | 1400*2800 | 1600*2800 | 1600*3100 | |
小过纸 Min.feeding size mm | 270*600 | 270*600 | 330*650 | 330*650 | 350*650 | 350*650 | 400*750 | 400*750 | |
间隙送纸 Intermittent paper feeding | 1000*1800 | 1000*2000 | 1400*2300 | 1400*2600 | 1600*2500 | 1600*2800 | 1800*2800 | 1800*3100 | |
大印刷尺寸 Max.printing mm | 900*1800 | 900*2000 | 1200*2300 | 1200*2600 | 1400*2300 | 1400*2600 | 1600*2600 | 1600*2900 | |
小开槽间距（反刀） Min.slotting size | 185*90*185*90 | 230*70*230*70 | 280*100*280*100 | ||||||
标准板厚 Print die thickness mm | 7.2 | ||||||||
适用纸板 Thickness of the paper | 1.5-12 | ||||||||
